2000KVA Cummins QSK60-G4 Container Generator Set Electrical Start

    Buy cheap 2000KVA Cummins QSK60-G4 Container Generator Set Electrical Start from wholesalers

    Buy cheap 2000KVA Cummins QSK60-G4 Container Generator Set Electrical Start from wholesalers
    • Buy cheap 2000KVA Cummins QSK60-G4 Container Generator Set Electrical Start from wholesalers

    2000KVA Cummins QSK60-G4 Container Generator Set Electrical Start

    Ask Lasest Price
    Brand Name : SHX
    Model Number : -SCS2200
    Certification : ISO9001:2015 , CE , TUV , BV
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 30 Sets per month
    Delivery Time : 20 working days
    • Product Details
    • Company Profile

    2000KVA Cummins QSK60-G4 Container Generator Set Electrical Start

    3 Phase Industrial Generators 2000KVA Container Diesel Generators Cummins QSK60-G4


    Features

    1. Universal design and manufacture.
    2. Most widely used around the world.
    3. With most service terminals.
    4. Engineers are familiar with Cummins powered gensets.
    5. You could find spare-parts very easy.

    Genset Specifications:


    Product Name2000KVA Diesel GensetModel-SCS2200
    Rated Power1600KW / 2000KVAStandby Power1760KW / 2200KVA
    Engine BrandCUMMINSAlternator BrandSTAMFORD
    Voltage400/230VCurrent2880A
    Frequency50HzRunning Speed1500RPM
    Phase3Power Factor0.8
    Dimension7059×2400×2700 mmWeight17660 KG

    Engine Specifications:


    Diesel Engine
    BrandIndia Cummins
    ModelQSK60-G4
    Number of Cylinders16
    Rotating Speed1500RPM
    Cylinder Arrangement60º Vee form
    CycleFour stroke
    AspirationTurbocharged and air-to-air intercooled
    Bore×Stroke(mm)159 x 159
    Displacement(L)65
    Compression Ratio13.9:1
    Speed GovernorEFC speed governor
    Cooling SystemClosed cycle water-cooled with fan drived by belt
    Speed Stability (%)≤5%
    Total Lubrication System Capacity (L)200
    Fuel Consumption at 100% Load199 g/kw.h
    Starting MethodDC 24V Electrical starting

    Alternator Specifications:


    Alternator
    BrandStamford
    ModelPI734F
    Number of Phase3
    Connecting Type3 Phase and 4 Wires
    Number of Bearing1
    Protection GradeIP23
    Altitude≤1000m
    Exciter TypeBrushless ,Self-excited, AVR automatic voltage regulation
    Insulation ClassH
    Telephone Influence Factor (TIF)≤50
    THF≤2%
    Voltage Regulation, Steady State≤±1%
    Transient State Voltage≤-15%~+20%


    QUALITY CONTROL & WARRANTY

    All generator sets should go through the rigorous testing before being released to the market place, including 50% load, 75% load, 100% load , 110% load and all protection functions (overspeed stop, high water temperature, low oil pressure and battery charging fail)
    Our factory warrants that the gensets will be free from defects in materials and workmanship for a period of one year from the date of shipment or 1200 hours, whichever comes first. If the product proves defective during the warranty period,our factory, at its option, will:
    (1) repair the product by means of telephone support or depot service at no charge for parts or labor,
    (2) provide the new spare parts to replace the broken one for maintenance.


    PROJECT PHOTO


    Quality 2000KVA Cummins QSK60-G4 Container Generator Set Electrical Start for sale
