350Kva Continuous Duty Diesel Generator 1500RPM Shangchai Engine

Ask Lasest Price
Brand Name :	SHX
Model Number :	SSF375
Certification :	ISO9001:2015, CE, TUV, BV
Price :	Negotiation
Payment Terms :	L/C, T/T
Supply Ability :	80 sets per month
Delivery Time :	15 working days

Add to Cart

Product Details
Company Profile

350Kva Continuous Duty Diesel Generator 1500RPM Shangchai Engine

350Kva Continuous Duty Diesel Generator 1500RPM Shangchai Engine

General Information:

1. Prime Power 280Kw / 350Kva, standby power 308Kw / 385Kva.

2. 50Hz, 400 Volt / 230 Volt, 3 Phase 4 Pole, 0.8 power factor, 1500RPM.

Genset Specifications:

Genset model	SSF350
Genset rated power	280KW / 350KVA
Rated voltage	400/230V (adjustable)
Rated current	504 Amps
Frequency	50 Hz
Power factor	0.8 Lagging
Connecting type	3 phase 4 wire
Cooling system	Closed cycle water-cooled with fan, water tank
Overall dimension (L×W×H) mm	3100×1200×1800
Gross weight (kg)	2500

Engine Specifications:

Diesel Engine
Brand	SHANGCHAI
Model	SC13G420D2
Engine type	6 cylinders in Line,4 stroke, direct injection
Aspiration	Turbocharged and air-to-air intercooled
Rotating speed	1500 RPM
Engine cooling system	Water-cooled
Speed governing system	Electronic speed governor
Starting method	By 24V batteries
Engine filter system	Dry type air filter ,fuel filter, oil filter, water filter
Displacement(L)	12.88
Bore×Stroke(mm)	135×150
Noise level (dB)	115
100% Load fuel consumption (l/h)	≤65.9
Lube capacity(L)	33

Alternator Specifications:

Alternator
Brand	FARADAY
Model	FD4LS1-4
Excite type	Brushless self-excited AVR regulation
Connecting type	3 phase 4 pole
Steady frequency change	0.50%
No load voltage	≥95%-105%
Steady voltage	≤±1%
Insulation class	Class H
Protection grade	IP23

Electrical Parameters

Wave distortion: <10%
Voltage fluctuation: <0.5%
Voltage / frequency fluctuation: <=0.5%
AVR self-regulated, voltage regulation rate: <=+- 1%
Radio interference restraining accords with stipulation of VDE0875-N and ISO8528

Control Function

Key start / auto start
Monitoring meters: Current; Frequency; Wire Voltage; Genset KVA; Genset KW; Output
Capacity; Output KW.H; Power Factor.
Warning/Shutdown: Alternator Under/Over Volts, Frequency; Under/Over Speed; Low Oil Pressure; High Engine Temp; High/Low Battery Volts; Over Current; Earth Fault Shutdown.
